Main Switchboards (MSBs)
Type-tested MSBs to 6,300 A with full segregation.
Our main switchboards form the heart of your site's electrical network. Engineered around verified Form 4b designs, each MSB is built for safe service-access, future expansion and full compliance with AS/NZS 61439.
Designed for the next 30 years
An MSB is a long-life asset. Ours are designed so that in year 12, when you need to add a feeder, you can — there's spare bus capacity, blank cubicles, and a cable entry layout that accommodates additions. Service access is front-only on most designs, so the board can sit against a wall and still be maintained.
Built to spec, every line.
- 01Up to 6,300 A bus rating
- 02Form 4b internal separation standard
- 03Withdrawable ACB and MCCB modules
- 04IP54 standard, IP66 optional
- 05Integrated metering and protection (Sepam, Micom, Easergy)
- 06Bottom or top cable entry, dual-source ready
- Standard
- AS/NZS 61439.1 / .2
- Rated current
- Up to 6,300 A
- Short-circuit
- Up to 100 kA / 1s
- Forms
- Form 1 → Form 4b
- IP
- IP54 standard, IP66 optional
- Cable entry
- Top or bottom
Main Switchboards (MSBs) — questions answered
Straight answers from our engineering team. Ask us directly →
Our type-tested designs extend to 6,300 A. Above that, we design and integrate paralleled ACB arrangements or move to multiple sectioned boards with bus-tie automation.
Yes. Multi-section boards are split into transport sections at the design stage, with site-joined busbars and pre-marked terminal blocks. Reassembly is a 1–2 day site activity.
Build it right the first time.
Send us your scope, single-line, or RFQ. A senior engineer responds within one business day.
